CASE WX145

Used CASE WX145 wheeled excavator — reference specifications, condition points and export notes for this model.

The CASE WX145 is a wheeled digging excavator weighing 15,300 kg with rated power of 121 hp (90 kW). A maximum dig depth of 5.3 m makes it suitable for medium-depth excavation, road works and site preparation where a wheeled undercarriage is preferred.

Description is a class-level reference built from the published specifications above; the exact unit's year, hours and condition are confirmed before payment.

Reference specifications

Reference specifications for CASE WX145
Operating weight	15,300 kg
Rated power	121 hp \| 90 kW
Max dig depth	5.3 m

Values are a public reference for this model. Confirm the exact unit's year, hours, condition and attachments before purchase.

Buying brief: CASE WX145

This is a 13 to 20 tonne class wheeled digging excavator, with an operating weight of 15,300 kg. It is powered by a 121 hp (90 kW) engine and can reach a maximum dig depth of 5.3 m. Machines in this class suit utility trenching, road works, drainage, and general construction where the excavator needs to move between sites. The weight and power give a balance of digging performance and mobility for medium projects. The size provides good reach for typical tasks while remaining roadable. The wheeled undercarriage allows travel on paved surfaces without a transporter, which can reduce mobilization time on projects with multiple small work areas.

The buyer should weigh ground conditions and tyre choice for this size. Stability can be affected by the oscillating axle and tyre pressure, so check the travel lock and steering modes. The 15,300 kg weight and 90 kW power are suited to a range of attachments, but the buyer should weigh the hydraulic requirements and the machine's lifting capacity at reach. Tyres wear differently from tracks, and replacement costs should be factored in. The turning circle and travel speed are advantages on road projects, but flotation on soft ground is limited compared with tracked machines. Before paying, inspect the engine for leaks, smoke, and unusual noise, and check the hydraulic system for responsiveness and contamination.

Pins and bushes in the boom, arm, and bucket linkage should be examined for play and wear. Wheel hubs and final drives need a check for oil leaks and bearing noise. Brakes, including the parking brake, should be tested on a slope if possible. Structural cracks around the kingpost, axle mounts, and boom foot are important to find. Also review the condition of the tyres and the steering mechanism, as repairs on these components can be significant. Shipping this size of wheeled excavator is typically done by container, flat rack, RoRo, or breakbulk, depending on the unit's dimensions and the destination port.

The operating weight of 15,300 kg and the overall height and width determine whether a flat rack or breakbulk is needed. For container shipment, the machine may need to be partially disassembled, but the wheeled undercarriage can simplify loading compared with tracked machines. RoRo is often used when the machine can be driven on and off the vessel. The final choice depends on the port's facilities, the shipping line's requirements, and the total dimensions after any preparation.

A class-level brief: it describes this size of machine and what to check. It is not a statement of availability or price for any specific unit.

Ask about this model↗Export & shipping

Common questions

Is a used CASE WX145 available right now?

Availability changes with stock. Send us the model and destination and we confirm the units currently on hand or that can be sourced.

What does a used CASE WX145 cost?

Price depends on year, working hours, condition, attachments and destination. We quote per unit, FOB China or CIF your port, after confirming the exact machine.

How is a CASE WX145 shipped from China?

Usually by container, flat rack, RoRo or breakbulk, chosen by the unit's real dimensions and your destination port. We plan loading before the balance payment.
