Yuanshan YS75W

Used Yuanshan YS75W wheeled excavator — reference specifications, condition points and export notes for this model.

The Yuanshan YS75W is a wheeled digging excavator built to China's Guosi standard, weighing 6550kg with a 0.27m3 bucket. Rated power is 48kw at 2200rpm, travel speed is 30km/h and maximum dig depth is 3344mm. It suits trenching and general site work.

Description is a class-level reference built from the published specifications above; the exact unit's year, hours and condition are confirmed before payment.

Reference specifications

Reference specifications for Yuanshan YS75W
Operating weight	6550Kg
Bucket capacity	0.27m3
Rated power	48Kw/2200rpm
Engine	48Kw/2200rpm
Travel speed	30km/h
Max dig depth	3344mm

Values are a public reference for this model. Confirm the exact unit's year, hours, condition and attachments before purchase.

Buying brief: Yuanshan YS75W

The YS75W is a wheeled digging excavator with an operating weight of 6550 kg, a bucket capacity of 0.27 m3, and a rated power of 48 kW at 2200 rpm. It meets China IV emission standards. This size suits municipal work, landscaping, small trenching, and utility maintenance where road travel between jobs is common. The wheeled undercarriage and compact dimensions make it practical for work in confined spaces, while the power and bucket size are matched to light to medium digging. It is often used by contractors who need one machine for multiple small sites.

On site, the wheeled undercarriage offers travel speeds up to 30 km/h, reducing the need for a transporter. Stability is influenced by tyre condition, steering play, and the use of a travel lock or stabilisers during digging. Buyers should consider tyre type and wear, the effectiveness of the steering and braking systems, and the range of attachments available. The machine's weight and footprint affect its suitability on soft ground, and the operator should understand load limits. Regular checks of the travel lock and hydraulic functions are part of safe operation.

Inspection should start with the engine, looking for oil leaks, exhaust smoke, and consistent power delivery. Hydraulic components, including the pump, valves, and cylinders, should be checked for leaks and smooth operation. Pins and bushes at the boom, arm, and bucket need assessment for wear. Wheel hubs, bearings, and brakes require close attention, as do the structural members for cracks or previous repairs. A thorough functional test and review of maintenance records help establish condition.

Shipping this model typically uses a flat rack or RoRo vessel, as its dimensions and weight may not fit standard containers without disassembly. The loading method is decided by the unit's real dimensions, the destination port's facilities, and the shipping line's requirements. Buyers should obtain accurate measurements and discuss lifting and securing with the carrier. Port handling capabilities and transport regulations also influence the choice between container, flat rack, RoRo, or breakbulk.

A class-level brief: it describes this size of machine and what to check. It is not a statement of availability or price for any specific unit.

Ask about this model↗Export & shipping

Common questions

Is a used Yuanshan YS75W available right now?

Availability changes with stock. Send us the model and destination and we confirm the units currently on hand or that can be sourced.

What does a used Yuanshan YS75W cost?

Price depends on year, working hours, condition, attachments and destination. We quote per unit, FOB China or CIF your port, after confirming the exact machine.

How is a Yuanshan YS75W shipped from China?

Usually by container, flat rack, RoRo or breakbulk, chosen by the unit's real dimensions and your destination port. We plan loading before the balance payment.
