Xinyuan B65ECO

Used Xinyuan B65ECO wheeled excavator — reference specifications, condition points and export notes for this model.

The Xinyuan B65ECO is a small wheeled digging excavator in the China IV emissions class. This class suits general digging, trenching and loading duties in confined sites, with a wheeled chassis for travel between jobs. Operating weight is 5500 kg, bucket capacity 0.18 m3, rated power 36.8 kw at 2200 rpm, travel speed 28 km/h, and maximum dig depth 3190 mm.

Description is a class-level reference built from the published specifications above; the exact unit's year, hours and condition are confirmed before payment.

Reference specifications

Reference specifications for Xinyuan B65ECO
Operating weight	5500kg
Bucket capacity	0.18m³
Rated power	36.8kw/2200rpm
Engine	新柴4D32X41P502
Travel speed	28km/h
Max dig depth	3190mm

Values are a public reference for this model. Confirm the exact unit's year, hours, condition and attachments before purchase.

Buying brief: Xinyuan B65ECO

This compact wheeled digging excavator sits in the under-8-tonne class, with an operating weight of 5500 kg, a bucket capacity of 0.18 m3 and a rated power of 36.8 kW at 2200 rpm. Machines of this size suit utility works, narrow-site excavation, trenching, landscaping and general construction tasks where a tracked excavator would be slow to reposition. The China IV emission rating applies to the listed engine, so buyers should confirm the engine variant fitted to a particular unit. The wheeled undercarriage gives good mobility on firm, level ground and reduces the need for a transporter on short moves.

The buyer should weigh stability on slopes and soft ground, tyre condition and type, steering response, and the presence of a travel lock or oscillation lock for safe digging. Attachment choices affect balance and reach, so check that the bucket or other tools match the intended work. Travel speed of 28 km/h is relevant for site-to-site movement, but road use depends on local rules and machine configuration. Before paying, inspect the engine for leaks, smoke and starting behaviour, and check the hydraulic system for pressure, hose condition and cylinder seepage.

Pins and bushes at the boom, arm and bucket should be checked for play, and wheel hubs for bearing noise or oil leaks. Brakes and the travel lock need a functional test. Structural checks should cover the chassis, articulation area if fitted, and any signs of repair or fatigue. Service records and a cold-start demonstration help confirm condition.

Shipping for this size is normally decided by dimensions and destination port. A compact wheeled excavator may fit into a container with the right preparation, or travel on a flat rack, by RoRo or as breakbulk. The choice depends on the unit's real dimensions, weight, attachment removal needs and the receiving port's facilities. Buyers should request dimensioned drawings and confirm lashing points, plus any import requirements, before agreeing a loading method.

A class-level brief: it describes this size of machine and what to check. It is not a statement of availability or price for any specific unit.

Ask about this model↗Export & shipping

Common questions

Is a used Xinyuan B65ECO available right now?

Availability changes with stock. Send us the model and destination and we confirm the units currently on hand or that can be sourced.

What does a used Xinyuan B65ECO cost?

Price depends on year, working hours, condition, attachments and destination. We quote per unit, FOB China or CIF your port, after confirming the exact machine.

How is a Xinyuan B65ECO shipped from China?

Usually by container, flat rack, RoRo or breakbulk, chosen by the unit's real dimensions and your destination port. We plan loading before the balance payment.
