Huaxin HXZL30-25

Used Huaxin HXZL30-25 wheeled excavator — reference specifications, condition points and export notes for this model.

The Huaxin HXZL30-25 is a wheeled digging excavator with an operating weight of 6800 kg and bucket capacity of 0.4-0.505 m3. Rated power is 61 kW at 2400 rpm, travel speed is 60 km/h and maximum dig depth is 4100 mm.

Description is a class-level reference built from the published specifications above; the exact unit's year, hours and condition are confirmed before payment.

Reference specifications

Reference specifications for Huaxin HXZL30-25
Operating weight	6800kg
Bucket capacity	0.4-0.505m3
Rated power	61Kw/2400rpm
Engine	4108
Travel speed	60Km/h
Max dig depth	4100mm

Values are a public reference for this model. Confirm the exact unit's year, hours, condition and attachments before purchase.

Buying brief: Huaxin HXZL30-25

The Hua HXZL30-25 is a compact wheeled digging excavator in the under-8-tonne class, with an operating weight of 6800 kg, a bucket capacity of 0.4 to 0.505 m3 and a rated power of 61 kW at 2400 rpm. Machines of this size suit utility trenching, drainage and small foundations, plus yard and road maintenance where the job moves between nearby sites. The bucket range covers general digging in soft to medium ground, and the 4100 mm maximum dig depth reaches typical service trenches without repositioning often. Buyers should match bucket choice to soil type and confirm the attachment suits the work planned. A wheeled undercarriage lets this class travel between jobs on its own wheels, and the listed 60 km/h travel speed supports road transfer where local rules allow.

On site the tyres give flotation on firm surfaces but less grip than tracks in soft or wet ground, so stability depends on outriggers or a dozer blade being deployed before digging. Buyers should weigh tyre condition and type, steering and brake behaviour, the travel lock for working, and whether the attachment set matches the tasks. Ground bearing pressure and site access also matter. Inspection before payment should start with the engine, checking for smoke, oil leaks and steady oil pressure when warm. Test the hydraulics through a full cycle of boom, arm, bucket and swing, listening for noise and watching for drift or weak function.

Check pins and bushes for play, wheel hubs for bearing noise and leaks, and brakes for even stopping. Look at the structure for cracks or poor repairs, especially around the boom foot, kingpost and outrigger mounts. Ask for service records where they exist. Shipping method for this class is decided by the unit's real dimensions and weight and by the destination port's facilities. Compact wheeled excavators often travel in a container where dimensions allow, otherwise on a flat rack, by RoRo where a regular service exists, or as breakbulk.

The 6800 kg weight and overall height with the boom stowed are the figures to confirm, along with any lowering of the boom or removal of attachments. Port handling equipment and sailing schedules then settle the final choice.

A class-level brief: it describes this size of machine and what to check. It is not a statement of availability or price for any specific unit.

Ask about this model↗Export & shipping

Common questions

Is a used Huaxin HXZL30-25 available right now?

Availability changes with stock. Send us the model and destination and we confirm the units currently on hand or that can be sourced.

What does a used Huaxin HXZL30-25 cost?

Price depends on year, working hours, condition, attachments and destination. We quote per unit, FOB China or CIF your port, after confirming the exact machine.

How is a Huaxin HXZL30-25 shipped from China?

Usually by container, flat rack, RoRo or breakbulk, chosen by the unit's real dimensions and your destination port. We plan loading before the balance payment.
